Nanofiltration

Nanofiltration

The characteristic of nano membranes is that the rejection of monovalent and divalent ions present in water is different.

It allows for selective removal. Their main applications include the recovery of special chemicals, such as developers, dyes, etc., and expensive raw materials, and the removal of some of the monovalent ions while significantly reducing the concentration of divalent ions in seawater desalination plants.
Product name Flow rate (GPD, m3/d) Salt rejection rate (%) MgSO4 rejection rate (%) Diameter/length (inch) Evaluation criteria Product specification
NE8040-40* 12,000 (45.4) 99.0 8.0 / 40 NE Standard
NE8040-70* 9,000 (34.1) 99.0 8.0 / 40 NE Standard (MgSO4)
NE8040-90* 8,000 (30.3) 8.0 / 40 NE Standard
NE8040-ARM 5,400 (20.4) 99.0 8.0 / 40 NE Standard (MgSO4)
NE8040-SRM 8,500 (32.2) 99.5 8.0 / 40 NE Standard (MgSO4)
NE4040-40* 2,500 (9.5) 99.0 4.0 / 40 NE Standard
NE4040-70* 1,900 (7.2) 99.0 4.0 / 40 NE Standard
NE4040-90* 1,700 (6.4) 4.0 / 40 NE Standard (NaCl)
NE4040-ARM 1,100 (4.2) 99.0 8.0 / 40 NE Standard (MgSO4)
NE4040-SRM 1,800 (6.8) 99.5 8.0 / 40 NE Standard (MgSO4)
NE Standard test conditions: NaCl 2,000 mg/L, Pressure 75 psig, Temperature 25°C, pH 6.5-7.0 Recovery 15%
MgSO4 rejection test conditions: MgSO4 2,000 mg/L, Pressure 75 psig, Temperature 25°C, pH 6.5-7.0 Recovery 15%
The stated data were obtained after 30 minutes of operation
* These models are tested and certified by NSF to NSF/ANSI/CAN 61.
For more certification details, Click here
